Water Heater Selection Methodology
After sizing determines the required capacity, selection methodology chooses the right heater configuration: single unit, multiple staged units, or tankless. Here is how.
Introduction
Water heater selection goes beyond sizing - it involves choosing the right type (storage, tankless, boiler, heat pump), the right configuration (single vs staged), and the right model from a catalog. Plumbing Booster supports both generic and catalog-based selection modes.
Generic Mode (B2 Auto-Staging)
In generic mode, the software uses B2 auto-staging:
1. Calculate the required envelope (storage + recovery).
2. Find the minimum number of units (k) that meet the envelope, where k <= maxUnits.
3. Optionally apply N+1 redundancy (add one standby unit).
4. Each unit is sized for envelope/k.
Example: Required = 200 gallons storage, 100 GPH recovery. Max units = 4.
- 1 unit: 200 gal, 100 GPH (may exceed available model sizes)
- 2 units: 100 gal, 50 GPH each (more practical)
- With N+1: 3 units installed, 2 operating
The user can adjust maxUnits and toggle N+1.
Catalog Mode
In catalog mode, the software matches actual products:
1. Filter catalog by heater type (storage, tankless, boiler, heat pump).
2. Match units to the required envelope.
3. Preferred manufacturer/brand is a soft preference (boost score) but does not hard-filter.
4. Other brands appear as alternatives.
5. Select the best match based on capacity, efficiency, and preference score.
The built-in catalog includes AO Smith/AOSmith specifications. Additional manufacturer catalogs can be imported.
Tankless Sizing
Tankless (instantaneous) water heaters are sized differently:
- No storage - heated on demand
- Sized by peak flow rate (GPM) at the required temperature rise
- Temperature rise = Hot water temp - Cold water inlet temp
- Must meet peak instantaneous demand, not daily usage
Plumbing Booster handles tankless sizing in both generic and catalog modes.
How Plumbing Booster Automates It
The Water Heaters module supports per-heater sizing method, selection constraints, and peak-window analysis (Method 2). The Summary page shows:
- Sizing method and results
- Selected heater type and configuration
- Selection status (enabled/disabled)
- Per-heater details (capacity, recovery, efficiency)
- Issues and validation warnings
